Connect All of Your Devices
Expand your wired home network with the D-Link® 8-Port 10/100 Desktop Switch (DES-1008E). By connecting the DES-1008E to your router, you can add up to four more computers to your home network with Fast Ethernet connectivity. Add devices like your gaming console, printer, print server, Network-Attached Storage (NAS) or network camera with a simple Ethernet cable.
Compact Design
This Desktop Switch fits virtually anywhere because of its compact size. Its power connector and ports are conveniently located in the rear to avoid messy cables on the desk. This Desktop Switch can also be mounted on a wall or underneath a desk with the included wall mounting kit.
Effortless High Speed Networking
Features easy access auto sensing 10/100 front Ethernet ports with a LED indicator for each port to quickly distinguish link status and activity. The DES-1005E switch also supports Auto MDI/MDIX Crossover allowing each port to be plugged directly to a server, hub, router, or switch using regular straight-through twisted-pair Ethernet cables to get you the maximum speed possible for each device connected to your network.
Plug and Play Installation
TheD-Link® 8-Port 10/100 Desktop Switch is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free. But we know that setting up your switch is only the beginning; you can also easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multi-player gaming environment.
Key Features
Inexpensive Fast Ethernet solution for home/SOHO
8 10/100 Mbps Fast Ethernet ports
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds
IEEE 802.3x Flow control
Plug-and-play installation
RoHS compliant
Switching Fabric
1.6 Gbps switching fabric
Standards
IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
ANSI/IEEE 802.3 Nway autonegotiation
IEEE 802.3x Flow control
Protocol
CSMA/CD
Data Transfer Rates
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex)
Topology
Star
Media Interface Exchange
Auto MDI/MDIX adjustment for all ports
Network Cables
10BASE-T:
UTP CAT 3/4/5/5e (100 m max.)
EIA/TIA-586 100-ohm STP (100 m max.)
100BASE-TX:
UTP CAT 5/5e (100 m max.)
EIA/TIA-568 100-ohm STP (100 m max.)
LED Indicators
Per port: Link/Activity
Per device: Power
Transmission Method
Store-and-forward
Mac Address Table
2K entries per device
Mac Address Learning
Automatic update
Packet Filtering/Forwarding Rates
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Ram Buffer
57 KBytes per device
DC Input
External 5V/1.2A power adapter
Power Consumption
Power on (Standby):
DC input: 0.6 watts
AC input: 1.4 watts
Maximum:
DC input: 3.3 watts
AC input: 5.2 watts
Heat Dissipation
Power on (Standby): AC input 4.774 BTU/h
Maximum: AC input 17.732 BTU/h
Temperature
Operating: 0 to 50 °c (32 to 122 °F)
Storage: -10 to 70 °c (14 to 158 °F)
Humidity
Operating: 10% to 90% RH Non-Condensing
Storage: 5% to 90% RH Non-Condensing
Device Dimensions (W x D x H)
6.5” x 4.4” x 1.5” (164.5 x 111.5 x 36.0 mm)
Certifications
FCC class B
ICES-003 class B
CE class B
C-Tick class B
VCCI class B
cUL
CB
MTBF
832,413 hours
Warranty
Limited Lifetime1
THIS Switches is BRAND NEW
Sealed In Box
2 Available
DON`T MISS OUT
1.I only sell and ship within South Africa
2.Pricing includes VAT.
3.Payments must be made within 24 hours after the auction closes, unless stated otherwise in the description of the item.
4.If payment is not received in 24 hours: NEGATIVE rating will be given, In cases where the selling price was more than R1000-00; I may also consider reporting non-payers to the Credit Bureau, as you did in fact enter into a legal contract.
5.Payments are only considered to be “received” when it reflects on my bank statement, and only then will parcels be posted or released.
6.I reserve the right to close any auction at any time. I also reserve the right to delete any bid/s for whatever reason. If you are a “no rating” bidder, please contact me via the Q & A service and we will take it from there.
7.DO NOT BID IF YOU DO NOT ACCEPT THESE TERMS & CONDITIONS OF SALE and bid only if you intend to purchase the item.
