---Brand New ---- Network cable tester (RJ45 & RJ11)

Products Name : Network Telephone Cable Tester RJ11/12,RJ45


Specifications:
1. Can test correspondingly double-twisted cables 1.2.3.4.5.6.7.8 and G meanwhile. can judge wrong connection, short circuit and open circuit

2. NS-468b tests BNC ,RJHand Rj45; NS468n tests RJ45 and BNC; ST-248 test RJ45 and BNC

3. If one cable, for example cable No.3 is open circuited, the two No.3 lights of the main tester and remote tester will not turn on.

4. If several cable are not connected , several lights will not turn on respectively , if less than two cables are connected ,none of lights is on.

5. If two ends of a cables is disordered , for example No.2 and No.4 then dispays on:
Main Tester : 1-2-3-4-5-6-7-8-G
Remote Tester:1-4-3-2-5-6-7-8-G

6. If two cables are short Circuited, neither of the corresponding lights is on of the remote tester while ,main tester remains unchanged. if three cables, including three, are short circuited, none of the corresponding lights is on .

7. If test patch panels or wall plate outlets, two cables which can match each other (eg 110P4 AND RJ45) will be connected to the tester.

8. If test cables of the same axes, BNC turns on when the Cable works.
