Wireless | |
Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Signal Rate | Up to 300Mbps |
Frequency Range | 2.4-2.4835GHz |
Transmit Power | 20dBm(MAX) |
Data Transfer Rate | 802.11n: 40MHz(300Mbps, 270Mbps, 240Mbps, 180Mbps, 120Mbps, 90Mbps, 60Mbps, 30Mbps) 20MHz (144Mbps, 130Mbps, 115Mbps, 86Mbps, 57Mbps, 43Mbps, 28Mbps, 14Mbps) (Auto-Sense) 801.11g: (54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps) 802.11b: (11Mbps,9Mbps, 6Mbps, 5.5Mbps, 2Mbps, 1Mbps) |
Wireless Mode | AP, WDS, AP+WDS, Repeater, Client, Multiple AP |
Wireless Security | 64/128-bit WEP, WPA-PSK/WPA2-PSK (TKIP/AES) SSID Broadcast Enable/Disable Wireless MAC Filtering |
Hardware | |
Standards | IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX |
Interface | 1 * 10/100M Auto MDI/MDIX RJ45 WAN port 4 * 10/100M Auto MDI/MDIX RJ45 LAN port |
LED | PWR,WPS, WAN, 1X-4X |
Button | Default, WPS |
Antenna | 2 * internal 4dBi antennas |
Power Supply | DC 9V/500mA(Output) |
Dimensions (L xW x H ) | 49 x 88 x 115 mm |
Weight | 112 g |
Software | |
WAN Type | DHCP(Dynamic IP), PPPoE, Static IP, WISP |
Port Forwarding | Virtual Servers, Port Triggering, UPnP, DMZ, FTP Private Port |
QoS | WMM, Bandwidth Control |
Access Control | IP/MAC/Domain filtering |
VPN Pass-through | PPTP, L2TP, IPSEC |
Others | DDNS, Static Routing, WOL, Remote Management, Firmware upgrade |
Others | |
Certification | FCC, CE |
Environment | Operating Temperature: 0âÂÂÂÂÂÂÂÂÂÂÂÂ~40â Storage Temperature: -40âÂÂÂÂÂÂÂÂÂÂÂÂ~70â Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Package | 1 * WF2420 1 * Setup CD 1 * Power Adapter 1 * Ethernet Cable |
