Features:
New WIFI power of ELM327 is the newly developed wireless scan tool.
It supports all OBD-II protocols Works with all OBD-II compliant vehicles:
Wireless (WIFI)
Supports APPLE Devices
Supports ISO 9141, KWP2000
Supports SAE J1850
Supports CAN bus
Functions:
* Read diagnostic trouble codes, both generic and manufacturer-specific,
and display their meaning (over 3000 generic code definitions in the database).
* Clear trouble codes and turn off the MIL ("Check Engine" light)
* Display current sensor data, including:
* Engine RPM
* Calculated Load Value
* Coolant Temperature
* Fuel System Status
* Vehicle Speed
* Short Term Fuel Trim
* Long Term Fuel Trim
* Intake Manifold Pressure
* Timing Advance
* Intake Air Temperature
* Air Flow Rate
* Absolute Throttle Position
* Oxygen sensor voltages/associated short term fuel trims
* Fuel System status
* Fuel Pressure
* Many others...
1.Wifi Settings
Search wifi -- Connect to device (SSID: OBDDevice/CLKDevice)
Static Tab -- IP Address: 192.168.0.123 -- Subnet Mask: 255.255.255.0
2.Software Settings
Open Software (your iOS sofware (ex: Rev DashCommand, FuzzyCar ))
Settings: Interface type : ELM -- Data Port : tcp://192.168.0.10:35000
