10.24kWh 51.2V 200AH ESENER Lithium Battery

THIS BATTERY HAS A 5 YEAR WARRANTY

With a built-in battery management system, The ESENER 51.2V 200Ah effectively avoids overcharge, overdischarge, overcurrent, short-circuit and balance. The ESENER 51.2V 200Ah is a high quality lithium-ion phosphate battery with a lifecycle of more than 6000 at 80% DOD, and can be used for 10-15 years. The battery offers a low internal resistance with excellent continuous high current discharge performance.

Details

• Advanced BMS with current limiting factor
• CAN Bus, fully integrates and communicates with leading inverter brands (Growatt, SOLAX, LUXPower, DEYE, MUST, Voltronic, Victron, SMA, etc.)
• Excellent high temperature performance
• High Cycle Life and Service Life
• 1C High Performance Lithium Battery
• High Energy Density and Conversion Efficiency
• Complete with integrated Battery Management System
• Compartible with most inverters and chargers
• Low self-discharge
• Easy wall mount or shelf rack installation
• Heavy duty side handles for easy handling and mounting to the wall
• Built in protection for over-charge, over-discharge & over-temperature

Specifications

• Model: ES-10.24KWH
• Rated Capacity (5HR): 200Ah
• Voltage: 51.2V
• Discharge Cutoff Voltage: 40.0V
• Equalised Charge Voltage: 58.4V
• Maximum Continuous Charging Current: 100A
• Maximum Continuous Discharging Current: 100A
• C. Rating: 1.0C
• Weight: Approx. 98kg
• Display: LCD
• Parallel: Parallel connection up to 15 packs with full communications
• Dimensions (WxDxH): 673mm x 618mm x 193mm
• Ports: 1x CAN Bus, 1x RS-485 Battery Link ports, 2x Parallel Instruction Ports
• Cells:New Li-Ion Prismatic Cells
• Design Life: -/+ 15 Years
• Cycle Life @ 1C: +/-4000 Cycles @ 100% DOD, Above 6000 cycles @ 80% DOD
• Certification: CE, UN38.3, IEC, MSDS
• Outer Package Material: White bake lacquer steel case
• Operating Temperature: Charging: 0 to 50°C, Discharging: -10 to 50°C, Storage: -10 to 50°C
• Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting

Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.
