100w SOLAR PANEL POLYCRYSTALLINE ECO-PLUS SOLAIRE (18v - 110Wp)

 POLYCRYSTALLINE ECO-PLUS SOLAIRE 100Wp SOLAR PANEL

                                                            This product carries a 10 year carry-in replacement warranty.

                                                             Any faulty module gets replaced; send unit back to supplier and replacement will be sent.

                                                                       Power Life expectancy of panel:20 years 80% yield.

Specifications:

No.of cells and connections 36(4 X 9)

Cell: Polycrystalline solar cell 156mm X 128mm

MODULE SIZE (mm): 1190 x 670 x 35

Weight: 10 kg

 Product characteristics:

Open circuit voltage (Voc) 22.2V

Optimum operating voltage (Vmp) 18.4V

Short circuit current (Isc) 6.89A

Optimum operating current (Imp) 5.44A

Any faulty module gets replaced; send unit back to supplier and replacement will be sent.Maximum power at STC (Pm) 100Wp (Watts peak)

STC: Irrandiance 1000W/m2, Module temperature 25°C, AM=1.5

Limits:

Operating temperature: -40°C to + 85°C

Maximum system voltage: 1000V DC

Temperature and Coefficients:

Nominal cell operation temperature (NOCT) 48°C +/- 2°C

Current temperature %K 0.035

Voltage temperature coefficient MV/K -0.37

Power temperature coefficient %K -0.5
