Package weight: 0.02 kgTechnical parameters:
Voltage measuring range: 3.60V ~ 32.5 V Resolution precision: 0.01 V
Current measuring range: 0.00A ~ 5.00 A Resolution precision: 0.01 A
Power cumulative range: 0 ~ 999999 WH Resolution precision: 0.001 Wh
Capacity range: 0 ~ 999999 mAH Resolution precision: 0.001 Ah
Temperature: 0 ￢ﾄﾃ ~ + 80 ￢ﾄﾃ Resolution precision: 1 ￢ﾄﾃ
D+ Voltage: 0.000V ~ 2.999 V Resolution precision: 0.001 V
D- Voltage: 0.000V ~ 2.999 V Resolution precision: 0.001 V
Load impedance: 0 ~ 999 ohm Resolution precision: 1 ohm
Power metering range: 0 ~ 299.999 W Resolution precision: 0.001 W
Timing maximum time: 999 H 59 M 59 S Resolution precision: 1 S
Time to refresh: > 500 ms/time > 500 ms/times
Measurement rate: 0.5 times/s
Use large equipment of the same metal manganese bronze sampling resistor (1.0 mm diameter metal manganese bronze material < 0.05R)
Product size: 65 x 24 x 14 mm
Since the power flow: < 0.003 A (< 3mA )
Working temperature: - 10 ~ + 60 ￢ﾄﾃ
Working humidity: 10 ~ 80 (no doubt)
The pressure of work: 80 ~ 106 kpa
Cumulative capacity range: 0-99999 mah precision: 0.001 Ah (New features or D+ D- Voltage)
Specifications:
Item size: 65 * 24 * 14 mm
Net weight: 19g
Package weight: 28g
Color: Blue / Transparent (Optional)
Function characteristics:
1) 8192 pixels HD display;
2) D+ D- Voltage Tester
3) Memory power time data such as power;
4) The single monitoring shows charging voltage, current, power, power WH, mAH, charging time and other information;
5) USB is the copper pin and low resistance in sampling technology, access after almost does not affect the charging speed;
6) Wide voltage from 3.60 V to 32.5 V;
7) Low and lower power since the < 0.003 A ( < 3mA) 3.60V~32.5V / 0.00A~5.10A / 0 ~ 299.999W / 0 ~ 999999 WH / 0 ~ 999999 mAH / 0￢ﾄﾃ~+80￢ﾄﾃ / 0~999 ohm / 999H 59M 59S / D+ D- Voltage 0.000V ~ 2.999 V / Since the power flow: < 0.003 A
8. When the power is > 0.5W, the time will be calculated!
Important Tips:
1) Backlight default time is 10S time, through the key button, switch to the BL interface: 10S time interface, double-click or three-click to increase(+) time or decrease(-) time the backlight time, and the same time backlight switch "BL: OFF(time) ~BL: ON( time) 1S ~ 59S range" Increase(+) or three-Click(-) after the reduction, then long press key is a continuous increase in the reduction.To meet the individual needs of users.
BL: 10S→ USB tester default backlight time is 10S, 10S automatically turn off screen brightness
BL: ON→USB tester backlight is on, always on
