12V 5V Fully Isolated Switching Power Supply AC-DC Module 220V to 12V

12V 5V Fully Isolated Switching Power Supply AC-DC Module 220V to 12V

Feature:

The power supply is fully isolated industrial grade built-in power module with temperature protection, overcurrent protection and short circuit full protection, AC85 ~ 265V wide voltage input, high and low voltage isolation, DC12V1A 5V1A dual isolated output voltage, 431 regulated, output with EMI filter circuit, with light, with mounting holes, cost-effective.

Working temperature: -20 a to 60 a
Relative humidity: 40% RH - 90% RH
Input voltage range: 85V - 265V (typical: 110/220) (under full load conditions)
Input Current: 0.027 (AC110V) 0.0136 (AC220V) (under full load conditions)
Input surge current: 20A (under full load conditions)
Size: 7.5 x 4.0 x 4.0 (cm)

Output regulation characteristic:

Output voltage	Minimum current	Maximum current	Peak current	Output voltage range	Ripple
+12V	0A	1A	1.2A	11.80~12.5V	150mV
+5V	0A	1A	1.2A	4.90~5.1V	80mV

Other output characteristics:

Item	Unit	Min	Typical values	Max	Test Conditions
Output Power	W	0	17	18.5	DC output power
Output efficiency	%		84		Rated load
Boot shutdown overshoot	%			10
The output rise time	mS			100

Protection:

Item	Unit	Yes/No	Min	Typical values	Max	Recovery characteristics
Output voltage	V		13		13.5	Lock, restart after recovery
			5		5.4	Lock, restart after recovery
Output Power Protection		Yes	17		19	Lock, restart after recovery
Short circuit protection		Yes				Lock, restart after recovery
Temperature Protection		Yes	90ﾣC		105ﾣC	Lock, restart after recovery
Overcurrent protection		Yes				Lock, restart after recovery

Package included:

1 x Fully Isolated Switching Power Supply




,
