16 Channel H.264 IP Networking Digital Video Recorder DVR
Included Client software/Support Internet Explorer 7 or above / Chrome/ Firefox
Support Android, Windows mobile, symbian, iPhone, Blackberry
VGA port for LCD monitor
Operate by USB Mouse or Remote Control (Both included)
+
This Supreme stand alone H.264 16 Ch DVR System is amazing.
The system has really amazing functions
Motion detection, sensor trigger Alarm, Audio, remote monitoring, PTZ, Alarm
Multiplex operation
Full Audio recording , PTZ preset and Cruise Control
Backup with USB , Movable hard disk , Network
Nerwork support UPNP function , easy for setup
Mobile phone surveillance (Win CE/Symbian/iPhone /Blackberry/Android)
Supports HDD up to 2TB
Main features:
Item: 16CH Network H.264 DVR
Video Input / Output: NTSC / PAL: BNC 16CH Video Input / 1CH Output
Audio Input / Output: Audio In: RCA 2CH
Audio Out: RCA 1CH,
Operating system: Embedded LINUX OS
Recording Resolution & Frame Rate: NTSC: 480FPS@CIF
PAL: 400FPS@CIF
Playback Resolution & Frame Rate: NTSC:30fps/1CH(CIF)ï¼ÂÂÂÂÂÂÂÂÂÂ
PAL: 25fps/1CH(CIF)
Video display: 16/8/4/1 channel
Multiplex operation: Live, Recording, Network, Mobile phone, Surveillance Simultaneously
Compression Format: Video:H.264 Baseline Compreession; Audio: G.726 8k*16bit ADPCM Mono
Hard Disk Capacity: SATA interface HDD x 1,Up to 2TB
Recording Mode Manual/ schedule/sensor trigger/motion detection/power-on auto record
Recording quality: High Normal Low
Sensors, Alarm 8 Input, 1 Output
Recording playback: 1/4/8/16 channel playback simultaneously(Optional playback channel),Support remote file playback,Rapid play by times(Fast Backward),Play by frame etc.
Network and protocol: 1 RJ-45 10/100M via Ethernet,Support TCP/IP,DHCP,DNS,DDNS,NTP etc.
Media Backup: 1 USB 2.0 port for USB flash disk
PTZ Control: RS-485,Support tracking routes,Pelco-D,Pelco-P
Email Alarm: Send pictures to the designated Email
Client Software: Client Software
Dual Stream: Support(main and secondary interchange)
Group play: Suport five users online access
Mobile phone surveillance: Support Windows, Symbian, Iphone, Blackberry, Android
User Authority: Suport Multi-level user authority distribution
IR Remote Control Unit: Yes
USB Mouse: Yes
