• H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
• Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input
• Up to 4 MP lite resolution for recording
•Supports real-time 1080p lite and when enabled, the image effect is similar with 1080p
• Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
• 4/8/16-ch synchronous playback
| Video/Audio Input | ||
|---|---|---|
| Video Compression: | H.264 | |
| Analog Video Input: | 16-ch | |
| Supported camera types: | Support HDTVI input: 720P/25, 720P/30, Support AHD input: 720P/25, 720P/30, CVBS | |
| Audio Compression: | G.711u | |
| Video/Audio Output | ||
|---|---|---|
| HDMI/VGA Output: | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz | |
| Frame Rate: | 1/16 fps ~ Real time frame rate | |
| Stream Type: | Video/Video&Audio | |
| Audio Output: | 1-ch RCA(Linear, 1kΩ) | |
| Audio Bit Rate: | 64kbps | |
| Dual Stream: | Support | |
| Synchronous Playback: | 16-ch | |
| Network management | ||
|---|---|---|
| Remote connections: | 128 | |
| Network protocols: | TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS | |
| Hard Disk Driver | ||
|---|---|---|
| Interface Type: | 1 SATA Interface | |
| Capacity: | Up to 6 TB capacity for each disk | |
| External Interface | ||
|---|---|---|
| Network Interface: | 1; 10M / 100M self-adaptive Ethernet interface | |
| USB Interface: | 2 USB 2.0 Interfaces | |
| General | ||
|---|---|---|
| Power Supply: | 12V DC | |
| Consumption: | ≤20W(without hard disks) | |
| Working Temperature: | -10 ºC ~+55 ºC (14 ºF ~ 131 ºF) | |
| Working Humidity: | 10% ~ 90% | |
| Dimensions: | 285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch) | |
| Weight: | ≤ 1.2 kg / 2.6 lb(without hard disks) | |
