DVR Features:
Embedded Linux OS
H.264 Hardware Compression
Video Input / Output: BNC 16/BNC 1
Video Output: VGA
Audio Input / Output: RCA 2/RCA 1
Signal System: NTSC / PAL
Video Speed:PAL: 25 frames / sec (adjustable) NTSC: 30 frames / sec (adjustable)
Monitoring quality:Pal: (QCIF)176*144, (CIF)352*288; NTSC: 720x480(D1)
Recording Mode: Continuous/ Time Scheduled/ Motion Detected
Network: RJ45
Remote Access: Internet Explorer or Netviewer Software
Support Remote View via Smart Phone & 3G Mobile:
a) iPhone™;
b) Google Android™;
c) Blackberry™ OS V4.7
d) Windows Mobile™; Pro 5.0 & 6.1
e) Symbian™ S60 3rd & S60 5th
PTZ via RS-485 Port
Plug-n-Play
Application Drawing
How to install the HDD in DVR:
(We can not determine how much storage the HDD you need. so we didn't offer it for you. you can choice 500GB to 2TB HDD according to your requirement)
1.The screw for fixing the HDD
2.Unscrew the screw
3.Unscrew the screw again, Open the DVR
4.Connect the HDD to DVR motherboard
5.Place the right location of the HDD
6.Fix the HDD location
How to set up internet monitor:
1.go to www.dyndns.com
2.Apply for a free dynamic domain name
3.go to menu, then set up, then network, then DDNS, choice
provider dyndns, input the user name, password and domain.
4.connect the DVR with Router, theN go to LAN. set
DVR Http port to 88. default dev port 8607 for Remote
monitoring. mobile port 101 for mobile Remote monitoring.
5.go to router port setting. set up 8607 port ip same as DVR
ip. 101 port ip same as DVR ip. 88 port ip same as DVR ip too.
6.it looks as these.
7.input you dynamic domain name, notice add :88
8.then you can go to here. not need input passward. press
OK. then you can remotely access it. for mobile phone, it is
same. just need download TMeye APP.
How to set up the cell phone remote monitor
Download from this link to get the online software and manual. unzip it and then go to the cell phone monitor software folder. there are mobile monitor software and instruction.
Package includes
(1) R2016 DVR System without HD
(1) 12V/3A DC Power Supply for Security DVR
