Package weight: 0.10 kgFeatures:- High current, high voltage withstand capability
- Good impact resistance
- Lower contact resistance
- Innovative sealing, waterproof and dustproof design, reaching IP67
- can adapt to different specifications of cable, customer-defined length; can be equipped with different models of connectors (compatible with MC4).
- Excellent high and low temperature, waterproof, UV resistance, etc., suitable for long-term outdoor use
Specifications:￢ﾗ? Wire Thickness: 10 AWG
￢ﾗ? Stranding: 10
￢ﾗ? Cable current requirements ambient temperature: 60°C
￢ﾗ? Conductor maximum working temperature: 120°C
￢ﾗ? Rated voltage: 1000V DC
￢ﾗ? Rated current: 30A
￢ﾗ? Cable specification: 4 mm2
￢ﾗ? Number of shares of the cable: 56/0.3TS
￢ﾗ?Outside diameter of cable: 6.10mm
￢ﾗ? Waterproof and dustproof rating: IP67
￢ﾗ?Insulation Thickness: 0.075 inches
￢ﾗ?Nominal Outer Diameter: 0.28 inches
￢ﾗ?Approximate Net Weight : 17.54 ft/lbs
￢ﾗ?Ampacity 90ºC Wet/Dry: 40A
￢ﾗ?Conductors: Fully annealed stranded bare copper per ASTM B3. Class B Stranding
￢ﾗ?Insulation Jacket: Chemically crosslinked polyethylene
￢ﾗ? Ambient temperature: -40°C to +85°C
