2/4/6pcs GXservo GX3225MG 25KG Servo High Torque Digital Steering Metal Gear Ser... (MODEL: 6PIECES)

12 were available / new

R1,625.00

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

szulou3617

93.01 % Positive ratings

Buyer protection

How you're covered

Returns

Replacement Guarantee: 7 Days: We stand by this guarantee

Get it now, pay later

Condition

New

Location

International

Bob Shop ID

612424135

SELECTED OPTION:
MODEL: 6PIECES

GXservo GX3225MG 25KG High Torque Digital Servo Steering Metal Gear for DIY Robot RC Car Airplane ? ? Specification Control system: PWM control system Working angle: 90 `+ 5 a?? Temperature range: -20 degrees Celsius to + 60 degrees Celsius Direction: counterclockwise pulse 1500 To 2500 USEC Voltage range: 6.0V ~ 7.4V Driving method: Field effect quality tube driving Test voltage: AT 6.0V / AT 7.4V Motor type: Iron core strong magnetic carbon brush motor 1723 Torque: 22KG.CM/25KG.CM Potentiometer: Indirect transmission Speed: 0.18S / 60 degrees , 0.16S / 60 degrees Amplifier Type: Digital No-load current: 300MA / 450MA Size: 40 * 20 * 39MM Load current: 2300MA / 2900MA Weight: 60G (without accessories) Dead band width: 2 microseconds Ball bearings: double ball bearings Cycle: >15,000 times Gear material: imported copper steel material ? ? Note: ? (1) Under the static working current, Shengyu servo is energized, but there is no movement. (2) In the case of no-load current operation, Shengyu servos move under no-load conditions. (3) The current of Shengyu servo when outputting the maximum torque under the condition of locked rotor current (4) The baud rate can be modified to 500K, 250K, 128000, 115200, 76800, 57600, 38400 (5) The maximum number of available bus nodes depends on the power supply capacity and the allowable current specifications of the cable. (6) The stall torque is the maximum stall torque of the steering gear. The actual working torque is selected from 1 / 3- -1/5 of this value as suitable for the operating point. ? ? Package Included (optional) 1 x Servo
