2.4GHz PAT-330 150m Wireless A/V Sender and Receiver

4 Channel Wireless Audio Video AV Transmitter Receiver with IR Remote Extension

Use 2.4GHz ISM frequency band.
Support 4 groups of channels. You can select these channels to

avoid interference from signals of a wireless router, etc.
Wireless transmission is suitable for one-floor.
The transmitter and the receiver are used in the same channel in a pair and can be used in the modes of point-to-multipoint or multipoint -to-multipoint.
Compatible with DVD, DVR, CCD camera, IPTV, satellite STB, digital
TV STB and other AV output devices.
Superheterodyne 433MHz Wireless IR Remote Extender is fully
compatible with remote control signals of DVD, DVR, CCD camera,IPTV, satellite STB, digital TV STB and other AV devices.The product is equipped with super strong IR signal transmitting function or used in conjunction with an IR signal extension wire.Images received by means of radio are vivid and stable, the color is flamboyant, and the sound is clear. Supports video transmission of PAL/NTSC system and stereo audio

transmission.
Fully hardware-designed. There is no need to install software. Plug and play. Simple and convenient.
Dimensions: 10cm (L) ×8.5cm (W) ×3.0cm (H). 2.4GHz module is CE & FCC certificated. Wireless application is safe

and reliable.


 Product specification:

Transmitter: Frequency Band: 2.4GHz
A/V Input Port: RCA
Audio Input Level :1Vp-p(Stereo)
433MHz Sensitivity :-110dBm
Carrier frequency :38KHz
IR Transmitting Range :≥5m
Power Supply :DC 5V-1000mA

Receiver:
Sensitivity :-90dBm
A/V Output Ports :RCA
Video Output Level :1Vp-p(PAL/NTSC)
Audio Output Level :1Vp-p(Stereo)
IR Transmitter :Superheterodyne 433.92MHz
Carrier frequency :38KHz
IR Receiving Range :≥10m
Power Supply :DC 5V-1000mA

Attention:

1. This product is more suitable for transmissions in the same floor
2. open area transmition 150 meters
3. can transmit across a wall about 30 meters.
4. the maximum common walls on three sides within every use,
transmission distance of 12 meters.
5. when the specific application in the set-top box, regardless of the

number of receivers, received the same picture, same channel.
