2 PORT USB 3.0 EXPANSION CARD

2 PORT USB 3.0 EXPANSION CARD - TXB047

Product Specification

Model Number: TXB047

Chipset: NEC/uPD720200

Port Number: 2 x USB3.0

Interface: PCI Express 1x Slot

Dimension: 80 x 68 x 12.6mm

Support OS

Windows 10 (32/64), 8 / 8.1 (32/64), 7 (32/64), Vista (32/64), XP (32/64), 2000

Windows Server 2012, 2008 R2, 2003(32/64)

Mac OS 10.x (Intel based, tested up to 10.9)

Linux 2.4.x and later (Tested up to 3.5)

Environment

Operating Temperature: 0 -50

Relative Humidity: 10%-90% (non-condensing)

Storage Temperature: -0-80

Relative Humidity: 5%-90% (non-condensing)

Features

USB3.0 Specification Compliant, backward Compatible with USB2.0 & USB1.1

2 External USB3.0 Ports, 10x faster than USB2.0

Supports PCI-Express Rev. 1.0a

USB3.0 Data Transfer Rate up to 5Gbps

Plug and Play Installation
