Features: 20Key infrared Music LED controller adopts the advanced micro control unit. It is
used for controlling a variety of LED lamp. For instance, point-source light, flexible
strip light, wall washer light, glass curtain wall light and so on; it has many advantages
such as low cost, convenient connection and ease of use. Meanwhile you could adjust
brightness, static colors and color changing effects via infrared remote control. When it
is in sound-control mode, the colors will change with the music rhythm.
Specification: Working Temperature:-20ᆪC ~60ᆪC
Input Voltage:
DC 12 - 24V Output: 3 circuit
Maximum Current: 4A
Output Current: 2A
Static Power loss: < 1 W
Output Power: < 72W
Connecting Mode: Common anode
External Dimension: 63(L) X 35(W) X 22(H)mm
Packing Size: 88(L) X 65(W) X 40(H)mm
Package included: 1 X IR Controller
1 X Remote
1 X User Manual
