20 x 30mm 12V DC Electro Holding Magnet 10Kg Attractive Force (Silver, 22cm Cable)..!
Check my rate
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Product details
20 x 30mm 12V DC Electro Holding Magnet 10Kg Attractive Force (Silver, 22cm Cable)..!
Product Information
Introduction
Electro holding magnet can generate powerful attractive force under power-up state, and it has an effect
of ceasing or moving on adsorbent objects when installed on automation equipment. When it is applied to
the automatic processing production lines to delivering products or materials such as: delivery production
line, sorting machine, transfer arm, experimental facilities, medical treatment, polishing, incising and cutting,
the delivery operation is simple and easy to control, besides, remote operation is also approved. Electro
holding magnet is very different from common strong magnet, for it requires the surfaces of adsorption
objects are as smooth as possible, moreover, the adsorption plane should not be smaller than the magnet
adsorption surface. There should be nothing else between the magnet and the adsorbent object, that is to
say, they must contact and join with each other completely, otherwise, the attractive force would be
decreased. The effective distance is 0 (they must contact and joint with each other completely), and the
attractive force of all electromagnets would be very weak or 0 if the interval is wider than 1mm. Attractive
force means the suction generated by total contact between magnet adsorption surface and adsorbent
iron (magnetic metal) under power-up state.
Specifications
Color Black + blue + silver
Material NdFeB
English Manual/Spec No
Other Attractive force: 10kg
Voltage: DC 12V
Dimensions (cm): 25.0 x 3.0 x 3.0
Weight (kg): 0.081
Packing List
1 x Electromagnet (22cm-cable)
