Features:
Wide Frequency Range: With an output frequency range of 88-108MHz with 100KHz steps, you can select from 200 different frequencies to find the perfect channel for your broadcast.
Clear Signal Quality: High signal-to-noise ratio of 63dB and only 0.05%THD ensures your listeners receive a crystal-clear sound.
Compact & Portable: Weighing just 120g, this compact transmitter is easily portable, making it perfect for on-the-go broadcasting or for stationary use.
Easy Power Supply: Uses a convenient USB Type C interface for power supply, with a supply voltage of 5V and consumption current not exceeding 500mA.
Long Transmission Range: In an open field, the transmitter can reach a maximum distance of up to 2000M, ensuring wide coverage for your broadcast.
Specifications:
Output frequency: 88-108MHz 100KHz step (200 frequency transmissions)
Display: LCD
Output power: 0.5W
Supply voltage: 5V USB-type-C
Supply current: 500mA
Input Signal: Audio Stereo 3.5MM
Signal-to-noise ratio: 63dB0.05%THD
Weight: 120g
Transmitting interface: SMA female head with external thread and internal hole
Antenna requirements: 50 ohm pure resistive load, VSWR not higher than 1.5
How to Use:
Connect the antenna to the transmitter.
Connect the power supply using the included USB Type C cable.
Connect your audio source to the transmitter using the 3.5mm male audio cable provided.
Package Included:
1 x 0.5W FM Transmitter
