Ultimate Power Backup Solution!
Introducing a portable inverter battery system designed specifically for load shedding situations.
What is this portable inverter system?
It combines an inverter unit with a battery to deliver seamless power during outages. When electricity is available, it charges the battery, and during load shedding, it automatically switches to battery power. This ensures your essential devices like lights, TVs, computers, chargers, and Wi-Fi remain operational.
Solar integration: Add a solar panel to recharge your batteries, even when mains power is unavailable.
Battery Backup Duration:
Powering a device like a 150W TV, your system can provide backup for approximately 12-14 hours.
Maximizing Battery Life:
To keep your batteries fully charged, ensure the inverter system is plugged in and powered on at all times.
Dimensions:
60cm x 60cm x 49cm
Weight:
~50 KG
Understanding Charge Control: The main distinction between PWM and MPPT charge control methods is their efficiency. MPPT devices offer about 30% higher efficiency in charging compared to PWM systems. Match panel and battery voltages in PWM setups for optimal performance.
Key Specifications:
- High Voltage: VDC 500V
- Pure Sine Wave Solar Inverter: 3.5KVA/3500W, 100A
Features:
- Pure Sine Wave Output
- Output Power Factor of 1
- Wide PV Input Voltage Range (120VDC - 500VDC)
- Integrated 100A MPPT Solar Controller
- Supports Multiple Output Priorities: UTL, SOL, SBU, SUB
- Parallel Operation for up to 12 units (Parallel Version)
- Supports Both Single and Three Phase Parallel Operation (Parallel Version)
- Wireless Parallel Capability without additional current sharing cables
- RS485 Communication for Battery Management Systems (BMS)
- Battery Equalization Function for Enhanced Performance and Lifespan
Inverter Mode Specifications:
- Rated Power: 3500VA / 3500W
- DC Input: 24VDC, 158A
- AC Output: 230VAC, 50/60Hz, 23.5A
AC Charger Mode:
- AC Input: 230VAC, 50/60Hz, 23.5A
- DC Output: 27VDC
- Max Charge Current (AC): adjustable 30A to 60A
- Max Charge Current (PV + AC): 100A
Solar Charge Mode:
- Maximum PV Array Power: 4000W
- Minimum Solar Voltage: 120VDC
- Maximum Solar Voltage (VOC): 500VDC
- Maximum MPPT Charge Current: 100A
Ingress Protection Rating: IP21 (suitable for indoor use)
Product Dimensions: 38 x 55 x 20 cm
Weight: 9.65kg
What's Included:
1 x ECCO 3.5KW 24V 100A MPPT Hybrid Solar Inverter
1 x User Manual
System Components:
- 1 x 24V 3.5KVA Hybrid Inverter
- 1 x Multi-plug
- 2 x 12V Deep Cycle Gel Batteries (120AH each)
- 1 x Heavy Duty Lockable Box with Wheels
- 1 x Battery Fuse
- 1 x Male and Female Solar Connector
- 1 x Power Cable with Surge Protection
5-Year Repair Warranty on Inverter
