Features:ￂﾠ
Premium Material: advanced mainboard with SMT process, lightweight and small sized; excellent quality laser head, durable to use; well-designed button avoiding bad contact problem brought by long term use; all these ensures the stable and well performance of the engraver.
Wide Engraving Area & High Accuracy: longer X-axis and Y-axis, broaden engraving area reaching 320mmx190mm. High performance processor with high precision algorithm, ultra-high resolution CNC motor and good aluminum alloy lead rail, provide more effective and accurate carving job.
Easy Operation: this portable and compact laser engraver adopts T-shaped structure and no frame, reducing possibility of out-sync left and right bar, deforming, difficultly debugging such problems. And it is tested and split into 2 major modules, convenient for you to install.ￂﾠ
Convenient Use: it supports OTA to update mainboard hardware, wireless connection for you to transfer engraving files to mainboard SD card, offline working making you capable of previewing and engraving under no USB transfer cable condition.
Wide Applications Meeting Your Demand: you can engrave trademark, QR code, patterns, text and more with material wood, bamboo, leather, plastic, etc. Also you enables to use it to cut paper, wood, leather, non-woven fabric, paper flannel, kt board, foam, stickers and other plates within 5mm, non-transparent plastic sheets within 3mm, black acrylic within 1.5mm, etc.
Specifications:
Material: Aluminum Alloy + Acrylic
Main Color: Black
Input: AC 110-220Vￂﾠ
Output: DC 12V 5A
Plug Type: UK Plugￂﾠ ￂﾠ
Engraving Area: 320*190mm / 12.59*7.5in
Laser Head Model: BX20
Supported OS: Win 7 / 8 / 10
Supported Language: Chinese, English
Port: DC2.5, USB cable interface, SD card slot, WiFi AP
Supported Picture Format: jpg / bmp / png
Supported Font Format: All fonts in Win system, downloaded fontlib
Supported Connection: USB cable connection / Wifi wireless connection / Wireless transferring file to SD card for offline workingￂﾠ
Engraving Mode: Black-White Point Mode, Black-White Line Mode, Gray Point Mode, Gray Line Mode and Contour Mode.
Engraving Application Range: wood, bamboo, paper, plastics, leather, resin, acrylic, horns, etc.
Item Size: 445*401*128mm / 17.52*15.79*5.04in
Package Weight: 2.5kg / 88.18oz
Package Size: 500*208*105mm / 19.7*8.2*4.1in
Note:
Laser engraver only, other accessories are not included.
It is a DIY Kit, must be assembled by yourself.
Please wear glasses during use and avoid touching the laser directly with your eyes and skin.
Engraving effect is influenced by output power, engraving speed, material and more.
Before start offline working, make sure that the SD card has been inserted into the card slot.
Please put the controller and network router in the same room when using wireless connection.ￂﾠ
Please update both software and controller firmware to the latest version when upgrading.
Upload is only available with WLAN connection.
Due to manual measurement, there may be deviation.
Due to lighting, the item in picture and material object may slightly differ in color, please in kind prevail.ￂﾠ
Packing List:
1 * Frame Part A (Lower part)ￂﾠ
1 * Frame Part B (Upper part)
1 * Laser Head
1 * Controller Board
2 * Stepper Motor Wire
1 * Laser Wire
1 * USB Cable
1 * Power Supply
1 * Protective Glasses
1 * Hardware Installation Manual
4 * M5 Nut (For frame fixed)
2 * M3x12 Screw (For laser fixed)
2 * M3 Nut (For laser fixed)
2 * Wood Block
2 * Paper
