Features:
Pure sine wave output.
Fed the power to city net.
High utilization of solar energy by using MPPT (maximum power point tracking) technology.
Over current protection.
Reverse polarity protection, avoid machine fault.
Support stackable (connect in parallel for higher output).
LED indicators reflect well working condition or machine fault.
Environment friendly.
Simple and safe to install.
Specifications:
Power
230W
Solar Panels
Vmp35-39V;Voc42-46V
DC Input Range
22-45VDC
MPPT Voltage
28-36VDC
DC MAX Current
15A
AC Output Range
230VAC(190-260VAC)
Frequency Range
50Hz/60Hz(Auto control)
Power Factor
>97%
THD
<3%
Phase Shift
<1%
Efficiency
230VAC(190-260VAC)
Peak Efficiency
95%
Stable Efficiency
92%
Protection
Islanding; short-circuit; converse connection; low voltage; over voltage; over temperature protection
Work Temperature
-25-65 degrees
Work Environment Humidity
Waterproof design
Grade of Waterproof
IP67
Show
Red and green LED
Cooling
Thermal conductivity silica gel¿¿¿¿¿¿Natural cooling¿¿¿¿¿¿
Stand-by Power
1-2W
EMC
EN61000-6-3:2007 EN61000-6-1:2007
Grid Disturbance
EN 50178+EN 62109-1+VDE0126-1-12
Grid Detection
DIN VDE 1026 UL1741
Certificate
CE
Inverter Size
18 * 9.5 * 4.5cm / 7.08 * 3.74 * 1.77in
Inverter Weight
1.4kg / 3.08Lb
Package Size
27 * 20 * 11cm / 10.62 * 7.87 * 4.33in
Package Weight
1.8kg / 3.96Lb
Packing List:
1 * Micro inverter
1 * AC cord
1 * User manual(English)
