Description;
-This is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger, and battery charger to offer uninterruptible power support with a portable size
-Its comprehensive LCD display offers user-configure
-The new inverter is a piece of improved equipment to work with all types of batteries thanks to the introduction of the equalizer charge that the predecessor didn't have. New parameters are included in the menu to perform it
-This is a multi-function inverter/charger, combining the functions of an inverter, and MPPT solar charger, designed to provide a miniaturized and highly reliable power conversion efficiency solar cell array
-And maximize the DC power supply to charge the battery. This is the ideal inverter for small photovoltaic power plants, or for small houses alone, for indoor and outdoor use
Features;
-Pure sine wave output
-Output power factor 1.0
-Programmable supply priority for PV, battery, or grid
-User-adjustable charge current and voltage
-Wide PV input range [120vdc-500dc], 120A MPPT SCC
-Working without batteries on a sunny day
-Wifi monitoring function
-PV and electricity complementary
Specifications;
-Package Weight; 3500
-Package Dimensions; l=54cm x w=39.5cm x h=22.5cm
-Color; Green and Black
Input;
-Voltage; 230VAC
-Selectable Voltage Range; 170-280 AC [for personal computer]
; 90-280VAC [for home appliances]
-Frequency Range; 50Hz/60Hz[Auto sensing]
-AC Voltage regulation [Batt.Mode]; 230VAC+-5
-Surge power; 7000VA
-Efficiency [peak] PV to INV; 97%
-Efficiency [peak] BAT to INV; 94%
-Transfer time; 10ms [for personal computers]
; 20ms [for home appliances]
-Waveform; Pure sine wave
Output;
-AC Voltage regulation [Batt.Mode]; 230VAC-+5%
-Surge power; 7000VA
-Efficiency [peak] PV to INV; 97%
-Efficiency [peak] BAT to INV; 94%
-Transfer time; 10ms [for personal computers]
; 20ms [for home appliances]
-Waveform; Pure sine wave
Battery and AC Charge
-Battery voltage; 24VDC
-Floating charge voltage; 27VDC
-Maximum charge current; 80A
-Overcharge protection; 31VDC
Model: FS-1007
Item Code: W05024
What's in the box
24V MPPT 5KVA Pure Sinewave 120A Hybrid Inverter - FIVESTAR
