Specification
Voltage Rating | 1800 Volts DC |
Temperature Range | -40° to +90°C |
Flexibility Class | 4 & 5 |
Conductor Type | Flexible tin plated/ Copper class – 5CEI EN 60228 |
Insulation Material | XL Halogen Free FR |
Sheath Material | XL Halogen Free FR |
Sheath Colour | Black |
Bending Radius | 4 x Diameter of cable |
Application
Solar cables are suitable for the interconnection of various elements of photovoltaic systems. Suitable for fixed installation outside and inside without protection or inside pipes, ducts or similar closed systems High resistance against ozone, U.V. rays, oils, moisture and weather inclemencies. Suitable for use at an ambient temperature up to 90°C (120°C overload) and tested according to TUV-Rheinland 2 1169/08.2007 Standard. The estimated lifetime of these cables is at least 25 years.
Construction
Flexible tin plated copper class 5 CEI EN 60228, LSOH Rubber compound type G12, LSOH Rubber Compound t6ype M21. Single core cables, for photovoltaic and solar system use, elastomeric compound insulted and sheathed. Flame retardant, halogen free, and low smoke flexible cables for fixed laying, lifetime testing 20.000h/120°C.
