Price Negotiable
SERVER SPECIFICATIONS
2x Intel® Xeon® Processor E5-2620 v3
MEMORY:
16GB (4 x 4GB DDR4-2400) ECC Registered Memory
POWER SUPPLY:
2x Power Supply DPS-750XB A (750W each)
MOTHERBOARD:
Intel® Server Board S2600WT2R
Essentials
Product Collection
Intel® Server Board S2600WT Family
A rack optimized server board supporting two Intel® Xeon® processor E5-2600 V3/V4 family up to 145W 24 DIMMs
Memory Specifications:
Max Memory Size (dependent on memory type)1.5 TB
Memory Types DDR4 ECC RDIMM/LRDIMM 1600/1866/2133/2400
Max # of Memory Channels 8
Max Memory Bandwidth 153.6 GB/s
Physical Address Extensions 46-bit
# of Memory Slots 24
ECC Memory Supported
Processor Graphics
Integrated Graphics
Graphics Output VGA
Discrete Graphics Supported
Expansion Options
PCI Express Revision 3.0
Max # of PCI Express Lanes 84
PCIe x4 Gen 3 1
PCIe x8 Gen 3 1
Connector for Intel® I/O Expansion Module x8 Gen 3 1
Connector for Intel® Integrated RAID Module 1
I/O Specifications
# of USB Ports 8
USB Revision 2.0 & 3.0
Total # of SATA Ports 10
RAID Configuration SW RAID 0 1 10 optional 5
# of Serial Ports 2
# of LAN Ports 2
Integrated LAN 2x 1GbE
Embedded USB (eUSB) Solid State Drive Option
Package Specifications
Max CPU Configuration 2
PROCESSOR (dual):
2x Intel® Xeon® Processor E5-2620 v3
(Specifications per processor)
Product Collection Intel® Xeon® Processor E5 v3 Family
Code Name Products formerly Haswell
Vertical Segment Server
Processor Number E5-2620V3
Lithography 22 nm
CPU Specifications
Total Cores 6
Total Threads 12
Max Turbo Frequency 3.20 GHz
Intel® Turbo Boost Technology 2.0 Frequency 3.20 GHz
Processor Base Frequency 2.40 GHz
Cache 15 MB Intel® Smart Cache
Bus Speed 8 GT/s
# of QPI Links 2
TDP 85 W
Memory Specifications
Max Memory Size (dependent on memory type) 768 GB
Memory Types DDR4 2133/2400
Max # of Memory Channels 4
Max Memory Bandwidth 59 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported
Expansion Options
Scalability 2S
PCI Express Revision 3.0
PCI Express Configurations x4, x8, x16
Max # of PCI Express Lanes 40
Package Specifications
Sockets Supported FCLGA2011-3
Max CPU Configuration 2
TCASE 72.6°C
Package Size 52.5mm x 45mm
Advanced Technologies
Intel® Turbo Boost Technology v2.0
Intel® Hyper-Threading Technology
Intel® Transactional Synchronization
Intel® 64
Instruction Set 64-bit
Instruction Set Extensions Intel® AVX2
Idle States
Enhanced Intel SpeedStep® Technology
Intel® Demand Based Switching Yes
Thermal Monitoring Technologies Yes
Security & Reliability
Intel vPro® Eligibility
Intel vPro® Platform
Intel® AES New Instructions
Secure Key
Intel® OS Guard
Intel® Trusted Execution Technology
Execute Disable Bit
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® VT-x with Extended Page Tables (EPT)
NO HARD DRIVES INCLUDED
