3.5KVA 24V Pure Sinewave Hybrid Inverter & 25.1V 120ah Lithium Battery
Pure Sinewave Inverter
Built in Solar Charge Controller
Overload and short circuit protection
Cold start function
Auto 50A Built In Super Fast Charger
Color may vary white/cream/blue
Lithium Iron Phosphate Battery LiFePO4 25.1V 3.1KWh
Specifications:
Electrical Characteristics
Nominal Voltage: 25.1V
Energy: 3.1KWh
Charge Efficiency: 100% at 0.2C
Discharge Efficiency: 96-99% at 0.5C
Self Discharge, 1 month: <3%
Charge Parameters
Charge Mode: Constant charge at 0.2C to 28.0V
Charge Current: AC 30A
Maximum Charge current: DC 50A
Charge cut off Voltage: 28.0V±0.2V
Discharge Parameters
Maximum Continuous Current:50A
Peak Current: 100A
Discharge Cut-off Voltage: 22 V
Environment
Charge Temperature: OºC to 45ºC
Discharge Temperature: -20ºC to 60ºC
Storage Temperature: 0º to 40º C
Mechanical Specifications
Cell Material: LiFePO4
Case: Metal (Black or White)
Mass: 31kg
Connector: Barner Terminal or Anderson 175A
Design Life: 10 Years: 25ºC
Cycle Life: 6000 @ 50% DOD
Protection: BMS: Over charge, Over discharge. Over current, Short current, Cell balancing.
Display: LCD: With a LCD display screen
