3-in-1 Msata and M.2 SSD to PCI-E 4X and SATA3 Adapter with Heatsink
Check my rate
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Product details
| Product Attribute | |
|---|---|
| Interface Type : PCI Express,Other | Package : Yes |
| Model Number : 1506A | |
★Features:
1. Supports PCIE M.2 SSD (NVMe or AHCI,Key-M), PCIE 3.0 X4 32 Gbps bandwidth, apply to 2280/2260/2242/2230mm
2. Supports SATA-based M.2 SSD (Key-B / B +M), SATA 6 Gbps bandwidth, apply to 2280/2260/2242/2230mm
3. Supports mSATA, 30x50mm, SATA 6 Gbpsbandwidth
4. 3-channel SSD read/write LED indicator
6. Supports PCIe 2.0 ,3.0 and PCIe 4.0motherboard
7. Supports 3SSDs (M.2 PCIE-based SSDs, M.2 SATA-based SSDs and mSATA SSD) to worksimultaneously.
8. NVME M.2 SSDto PCIE 3.0x4 (32Gbps), no need to use SATA cable to connect to the PC.
9. When workingwith SATA M.2 to SATA III (6Gbps) and mSATA to SATA III (6Gbps), a SATA cableis required to connect the motherboard. (The product already contains 2 SATAcables)
10. this adapteris compatible for PCI-E 4X, 8X, 16X, but the speed only PCI-E 4X.
