3-Port HDMI switch
Check my rate
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Product details
3-Port HDMI switch
SKU: 3P14A
Features:
The 3-Port HDMI switch allows 3 HDMI ports to be switched to a single display terminal via remote control or buttons on unit
The switcher can be also placed at the end of a long HDMI cable to regenerate the HDMI signal. This HDMI Switch supports video formats including 720p, 1080i, 1080p
Support:
- 2.5Gbps date rate for tmds clock up to 250MHz
- HDMI 1.4a
- 3D
- highest video resolution 1080p/ 60Hz
- UXGA, WUXGA
- 8, 10 & 12 bit deep colour
- AWG26 HDMI standard cable Input up to 15metres & Output up to 25metres
- Single high definition display for multiple sources, such as DVD Players and Satellite Receivers, Digital Projectors, A/ V Receivers, Set Top Boxes
- Remote Control for operational flexibility and easy to control
Note:
No need to install drivers, portable, flexible, plug and play. If power supply is insufficient, you can also connect the external power adapter
Specifications:
HDMI version: HDMI 1.4a
HDMI resolution: 24/ 50/ 60fs/ 1080i/ 1080p/ 720p/ 576p/ 576i/ 480p/ 480i
Support video color format: 8/ 10/ 12 bit deep color
Support audio format: DTS-HD/ Dolby-trueHD/ DTS/ Dolby-AC3/ DSD
Max bandwidth: 250MHz
Max baud rate: 2.5Gbps
Input cable distance: ≤15m AWG26 HDMI standard cable
Output cable distance: ≤25m AWG26 HDMI standard cable
Max working current: 150mA
Operating Temperature range: -15 to +55¿
Operating Humidity range: 5 to 90%RH (No Condensation)
Return Policy
Unit malfunctioning, non operational etc. can be returned for replacement unit within 7 days of purchase. Thereafter repairs can be carried out on item or replacement unit can be authorised from manufacturer
