Feature:
- High-performance STM32 F722 MCU with speeds up to 216MHz.
- ICM42688P gyroscope, independent low-noise power supply.
- Various Ports for quick & easy setup: ESC port, Digital VTX port, Analog VTX port, Receiver port, and LED port.
- Built-in analog video OSD, 16 Mbytes black box,
- High power synchronous rectifier BEC, supports up to 8S input and provides stable 9V/3A & 5V/2A output.
Specification:
Brand: Holybro
Model: Kakute F722
Item Name: F7 Flight Controller
MCU: STM32F722 32-bit processor, 216MHz, 256Kbytes RAM, 512Kbytes Flash
IMU: ICM42688-P (SPI)
Barometer: BMP280
OSD: AT7456E
5x hardware UARTS (UART1,2,3,4,6)
7x PWM Outputs (6 Motor Output, 1 LED)
Onboard 16 Mbytes for Blackbox logging
Battery input voltage: 3S - 8S
BEC: 9V/3A, 5V/2A, 3.3V/0.2A
Connector
-2x JST-SH
