Description
Brass sheet is mainly used for riveting,cutting tools and all kinds of precision parts.
Having good mechanical properties and hot plasticity as well as good machinability, the sheets are easy to weld, and it has corrosion resistant, but easy to produce corrosion cracking.
It is one of the widely used ordinary brass varieties. Used for the loaded parts made of a variety of deep stretching and bending stress such as pin, rivets, washers, nuts, conduit, barometer spring, screen mesh, radiator parts,etc.
Specifications
Material: H62 brass
Dimension: 300mm x 100mm
Thickness: 0.5mm
FeaturesHeat treatment
Hot working temperature: 650 ~ 850 ¬トテ
Annealing temperature: 600 ~ 700 ¬トテ
Eliminate the internal stress of low annealing temperature: 270 ~ 300 ¬トテ.
Chemical composition of H62
Cu (%): 60.5-63.5
Fe(%): 0.15
Pb(%): 0.08
Ni(%): 0.5
Zn(%):35.27-38.27
Impurities(%): 0.5
Hardness: Y2
Tensile strength σb.N/mm2: 343-460
Elongation δ(%): ≥20
Electrical conductivity IACS(%): --
Reduction of area ψ(%): ≥18
Package included
1 x Brass Sheet
