0-30A Solar Regulator
30A Solar Charge Controller ST1 Series
A charge controller, or charge regulator is basically a voltage or current regulator to keep batteries from overcharging. It regulates the voltage and current coming from the solar panels going to the battery.
Parameter:
Model | ST1-30 | ST1-40 | |
Rated voltage | 12V/24V Automatic voltage recognition | ||
Max charge current | 30A | 40A | |
Max discharge current | 30A | 40A | |
Full charge cut | 16.5V/33V | ||
Low voltage cut | 11V/22V | ||
Low voltage restore | 12.6V/25.2V | ||
Temperature compensation | -3mv/ᅡ/cell | ||
Static current | ≤45mA | ||
Voltage drop | <220mv | <240mv | |
Wire area max | 6mm2 | ||
Net Weight | 400g | ||
ᅡross Wight | 500g | ||
Size (L*W*H) | 210*120*50 mm | ||
Packing quantity | 30pcs/carton | ||
Carton size (L*W*H) | 455*380*270 mm |
Feature:
ᅡCPU controlled with PWM function: able to adjust the charge current and decide if to supply the loads electricity according to the voltage of battery;
ᅡCompensation charging: according to various system temperatures, the controller will automatically compensate the temperature of the charging voltage;
ᅡLCD monitor: showing the charging current, battery voltage, environment temperature and real-time data of the charging process;
ᅡTemperature sensor: probing the temperature of environment and indicating the degree of charging.
ᅡAutomatic Identification System Voltage, 12V/24V auto recognition.
ᅡCompleted technical data for setup and modify.
ᅡDischarge capacity control
ᅡDischarge Counter of Ampere Hour
ᅡWorking Storage Function: record the total run time of system, record timers of error during running time, record times of full charged battery.
ᅡOver voltage protection, short circuit protection, over load protection, overcharge protection, over-discharge protection.
Application:
This solar charger controller is suitable for solar panel charger system and the basic element for the whole solar power system.
