3kW Hybrid UPS Solar Inverter (3500VA/3000W) Off-grid or Grid tied for Offices, Farms or Homes
Check my rate
| Main centres: | 1-3 business days |
| Regional areas: | 3-4 business days |
| Remote areas: | 3-5 business days |
Product information
The Integrated UPS Company 3.5KVA Hybrid Inverter is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support in a portable wall mount design.
It has a comprehensive LCD display offers user-configurable acceptable and easy-accessible button operation such as battery charging current. It is AC/solar charger priority, and acceptable input voltage based on different applications.
Product Specifications:
Output Power: 3500KVA/3000W
Output Voltage:230VAC
Input Voltage:230VAC
DC Voltage: 24VDC
Frequency: 50Hz/60Hz(Auto sensing)
NW: 10.06 kg. GW: 11.32 kg
Product dimensions: 40cm x 30xm x 12cm
Packing Size: 56cm x 39cm x 20cm
Product Features:
Full Sine Wave Hybrid Inverter
Use for Gel battery or Lithium Iron
Configurable input Voltage range for home appliances & Personal Computers via LCD setting
Automatic battery charging current based on current power of battery
Automatic AC Solar charger in built
Compatible with mains voltage or generator power
Auto restart while AC is recovering (should your batteries be completely depleted)
Overload, over temperature & Short Circuit protection (over current)
Smart battery charger design for optimized battery performance
Cold start function (will start once power or battery is reinstated)
WARNING:
Gel batteries should only be run down from 100% to 70% of capacity (depending on type of battery) otherwise the battery run time will deplete.
Lithium iron can be run down from 100% to 0-20% and will work fine
Lead Acid batteries (car & truck) do not have a deep cycle run and will not function for long
Does not include Surge protection (separate fuse and holders)
Must be installed by licensed electrician and must include COC upon installation
