Rated parameter | Symbol | Value |
DC supply voltage | VDD-VSS | 5V |
Storage temperature range (TS) | TSTG | -12ᆪC to 75ᆪC |
Welding temperature | +260ᆪC |
PIN | Description | |
1 | ANT | RF signal input pin, this pin should be connected to the antenna |
2 | VSS | Positive power supply |
3/4 | GND | Negative power supply |
5 | DATA | Data signal output, compatible with CMOS levels |
