Specification :
Strong structure with 1.2mm SGCC
Support ATX Motherboard (12” x 9.6”)
Support 4 slot full height size card (max. 175mm long)
Short 3U chassis at 380mm, may install two chassis at 3U layer space in cabinet
Removable front air filter
Hard drive Bay with anti-vibration function
Working Temperature max. up to 50âÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂÂ
Humidity 90% Non- Condensing
2 x Front 2.0 USB
2 x 80 x 80 x 25(mm) intake fans behind front air filter panel
2 x 5.25” Bay & 5 x 3.5” Hard Drive(extra 5.25” will be available when using micro ATX motherboard)
No switching power supply is include
Dimension : 428(W) x 133(H) x 380(D) (mm)
Optional Item
Standard ATX Switching power supply with 80mm fan
600mm full extension slide rail with three layers(65kg Loadable, Full extended to 1100mm travel)
