42BYGB48 DC 12V NEMA17 Stepper Motor with 300mm 1204 Ball Screw
+5

42BYGB48 DC 12V NEMA17 Stepper Motor with 300mm 1204 Ball Screw

New 20 available
R1,500.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Returns
Replacement Guarantee: 7 Days: We stand by this guarantee
Get it now, pay later

Product details

Condition
New
Location
International
Bob Shop ID
654085032
Description:
42BYGB48 DC 12V NEMA17 Stepper Motor with 300mm 1204 Ball Screw

Specification:
Model 42BYGB48
Voltage DC 12V
Current 1.8A
Power 5.8W
Speed 300-600rpm
Torque 0.58NM
Size 42 x 48mm
Phase 2
Step angle 1.8ᆪ
Step 200
Axial 30N 25N(5.6Lbs.)Push 65N(15Lbs.) Pull
Radial 30N (6.5Lbs.)
Temperature -20a~-50a
Model of screw 1204
Length of screw 300mm



Features:
Precise and efficiency.
Suitable for mechanical work.
Durable and long service life.

Package Included:
1 x 42BYGB48 NEMA17 Stepper Motor with Ball Screw

More Details:




Add to cart
