Connect up to 4 regular cameras and view and record the images
Magic Radar DVR card
PCI plug in connection
Multi-Mode display screen
High-speed playback search
Remote on-line viewing and playback via LAN, WAN, internet with web browser
Motion detection with variable screen selection
Alarm I/O interface
Pan/Tilt/Zoom control for cameras on platforms
Real-Time digital video compression using MPEG-4 Data Compression
Frames per second PAL: 25fps
Full resolution real time display: PAL: 768x576
4 x camera inputs with BNC sockets
One audio channel with phono socket
Support Windows 98 / ME / 2000 / XP
Data compressing format: MPEG-4
Network Connection: LAN, ADSL
PC requirements (VERY IMPORTANT)
VGA : ATI Compatible AGP Graphic Card, VIP(Video Input Port)Existence
Main board: No higher than Intel 845 chipsetResolution : 1024 × 768, 32bit Color
HDD : 30GB or moreBackup Storage : DVD R/W, Tape Backup System, etc
S/W : Direct X 7.0 or laterDriver : DVR Driver
We recommend that you use these or compatible components
INTEL 845G Motherboard http://www.newegg.com/Product/Product.asp?Item=N82E16813151160
INTEL P4 2.0 Gb (not AMD)
ATI VIDEO 7000 64 mb agp or pci-e card
256 Mb Ram
Captured video needs to be on a different drive from the OS
Included in the box: Capture card, software CD with user manual as a Word document
