Specifications:
Brand: iFligh
Model: XING2 1002
KV: 14000KV
Quantity: 4PCS ( 2CW+2CCW)
Weight(included wire): 2.7g
Dimension: 12.5*11.5mm
Interphase Resistance: 0.269
Input Volts: 8V
Peak Current: 6.87A
Max Watt: 53.2W
Mounting Holes: 6.6mm/1.4mm (3 mounting holes)
Rotor Specifications: Segmented bell
Shaft Diameter: 1.5mm
Shaft Protruding Length: 3mm
Lead: 50mm/28AWG/SH1.25 3P
Magnet: N52H Curved
Configuration: 9N12P
Bearing Type: NMB
Bearing Specification: 4*1.5*2.mm
Winding: Single Strand copper winding
Application: Original Replace Motor for iFlight Defender16 FPV Racing Drone
Features:
High-Performance KV: With a KV rating of 14,000, th
