4 Ton Long Reach Trolley Jack

Scissor Jack Overview:

A scissor jack is a type of mechanical lifting device commonly used for raising vehicles, typically for changing a flat tire. It is often included in the trunk (boot) of a car alongside a spare wheel. This jack operates via a wind-up mechanism, which uses a handle to turn a screw, causing the arms of the scissor jack to expand outward, lifting the vehicle. Scissor jacks are compact, lightweight, and affordable, making them a popular choice for emergency roadside assistance.

How to Use a Scissor Jack:

1. Preparation:

   • Position the Jack: Place the scissor jack on solid ground, as close to the vehicles lifting point as possible. Ensure the vehicle is on a flat surface and the handbrake is applied.
   • Loosen Lug Nuts: Before lifting the vehicle, use a wrench to slightly loosen the lug nuts of the flat tire while the vehicle is still on the ground.

2. Position the Scissor Jack:

   • Locate the vehicle's jacking point (usually near the wheel well, indicated in the vehicle's manual). Position the scissor jacks lift plate directly under this point.

3. Lifting the Vehicle:

   • Insert the Handle: Attach the handle to the jacks winding mechanism.
   • Wind the Handle: Turn the handle in a clockwise direction to raise the jacks arms. This will gradually lift the vehicle off the ground. Continue until the tire is fully raised.

4. Remove the Flat Tire:

   • Once the vehicle is lifted, remove the loosened lug nuts and take off the flat tire.
   • Replace with the spare tire and tighten the lug nuts loosely.

5. Lower the Vehicle:

   • After securing the spare tire, use the handle to reverse the wind-up mechanism, slowly lowering the vehicle back to the ground.
   • Once the vehicle is stable, tighten the lug nuts fully in a crisscross pattern to ensure proper fastening.

6. Finish:

   • Carefully remove the scissor jack and handle, and store them back in the vehicles trunk, along with the flat tire.

Specifications:

• Capacity:

  • Maximum Load Capacity: 4 Tons
  • This scissor jack can safely lift vehicles with a weight of up to 4 tons, making it suitable for most passenger cars and light trucks.

• Height Range:

  • Minimum Height: 150 MM
  • Maximum Height: 685 MM
  • This range allows the jack to accommodate a variety of vehicle sizes, providing sufficient lifting height for tire changes.

• Stroke/Travel:

  • Stroke / Travel: 535 MM
  • The jacks stroke provides ample lift for most vehicle tire changes, with fewer turns of the handle required to achieve the desired lift height.

• Lift Plate Dimensions:

  • Lift Plate Size: 150 x 150 MM
  • The lift plate is wide enough to provide stability when lifting the vehicle, ensuring the jack does not slip or become unstable during use.

• Handle Length:

  • Handle Length: 1.2 M
  • The handle length provides good leverage for easier lifting, requiring less effort to lift the vehicle to the desired height.

• Clearance:

  • Clearance: 150 MM
  • This clearance ensures the scissor jack can be easily positioned under vehicles with low ground clearance, making it ideal for most passenger cars.

Package Information:

• Package Weight:

  • Weight: 103.00 KG
  • The weight suggests the jack is built with durable materials that can handle the heavy lifting required, but it is likely packaged with additional components for protection during shipping.

• Package Dimensions:

  • Length: 157.00 CM
  • Width: 42.00 CM
  • Height: 27.00 CM
  • These dimensions suggest that the jack comes securely packaged, possibly in a case or box for storage.

Benefits and Applications:

• Compact and Portable:

  • Scissor jacks are small and lightweight, making them easy to store in the vehicles trunk without taking up much space, perfect for emergency use.

• Affordable and Simple to Use:

  • As one of the most cost-effective lifting options, a scissor jack is easy to operate, even for individuals with minimal experience in vehicle maintenance.

• Suitable for Light-Duty Use:

  • While it may not be suitable for heavy-duty lifting tasks, the 4-ton capacity is perfect for most standard cars, light trucks, and SUVs.

• Ideal for Emergency Situations:

  • Scissor jacks are widely used in roadside emergencies for changing tires, ensuring that drivers have the tools they need for quick fixes when away from home.
