5.5kW 110A Pure Sine Wave Inverter - High voltage, can work without batteries.
IP Rating:
- IP20
- Not recommended for installation location with high humidity.
- If the inverter needs to be installed close to the ocean please make use of a dehumidifier.
Features:
- Programmable supply priority for PV, Battery or Grid.
- User adjustable charge current & voltage.
- Wide PV input range 120 - 500 Vdc, 110A MPPT SCC.
- Can operate without batteries.
- Can be parallel connected , also 3-phase.
- Output power factor 1.0
- Wi-Fi monitoring function (Optional).
- PV & Grid complementary.
- Pure sine-wave Inverter.
- High voltage inverter.
Max Watt Output:
- Continuous: 5.5 kW
- Surge: (5 seconds) : 11 kW
Output and Charging Source Settings:
- Solar-Utility-Battery & Solar-Battery-Utility.
- Solar only: 110A (maximum).
- Grid only: up to 80A.
Solar input specifications:
- 120 - 450 Vdc and 20A solar input is the optimal working voltage range for these inverters.
- If operation without batteries is required, this input condition must be met.
Monitoring & Setting :
- LCD screen.
- Wifi dongle (optional) monitoring system via phone app.
Expansion: Single Inverter
- PV Panels maximum: 6000 W
- 9 x 550W panels MAX
- PV Panels connection : series only.
- Batteries minimum: 4 x 100Ah 12V / 48 V LiFePo4
- Can operate without batteries
- Peak Efficiency: 95%
- No Load Power Consumption: <50watt
Expansion: More Inverters
- Can be used as single inverter.
- Single phase & 3-phase up to 6 units
- Please take note that the warranty will only be valid for up to 3 inverters connected in parallel. Contact us for approval on warranty for more than 3 inverters connected in parallel.
Physical dimensions
- 472 x 297 x 133 mm
- 10.5 KG
What's in the box
- Inverter
- User manual
- Communication Cable
- Parallel Cable
- Power Sharing Cable
IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.
Warranty:
12 Months Warranty
Please take note of the full warranty terms and conditions.
