5.5a Bms 4s Active Balancer Board -ion Lifepo4 Lto Battery Capacitor Equalizer Power Transfer With

-ion\/Lifepo4 \/ version: 1,Balance start voltage: 3.0V-4.2V2,Balance termination voltage: 2.9V (into undervoltage sleep state)3,Maximum Balance current: The whole group error is 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)4,3S quiescent current Full state: (4.2v*3cell) 12.6V 12mA5,4S quiescent current Full state: (4.2v*4cell) 16.5V 15mA6,7S quiescent current Full power state: (4.2v*7cell) 29.4V 15mA7,8S quiescent current Full power state: (4.2v*7cell) 33.6V 14mA8,Whether external power supply is required: no external power supply is required, and the internal energy transfer of the battery is used to transfer and the entire set batteries pack in balance .9,Working environment temperature: 0-60 degreesLTO version1,Balance start voltage: 2.0V-2.8V2,Balance termination voltage: 1.9V (into undervoltage sleep state)Maximum Balance current: The whole group error is 0.1V1A; 0.5V3.5A; 1.0V5.5A (18awg 30CM cable test)3,5S LTO quiescent current Full state: 2.8v*5cell) 14V 12mA4,6S LTO quiescent current Full state: 2.8v*6cell) 16.8V 15mA5,Whether external power supply is required: no external power supply is required, and the internal energy transfer of the battery is used to transfer and the entire set batteries pack in balance .6,Working environment temperature: 0-60 degreesColour:As shownMaterial:PC+MetalPackage Contents:1 x 5.5A BMS 4S Active Balancer Board(with Protective Case)Only the above package content, other products are not included.Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +\/- 1-3cm.
