5.5kW High Voltage MPPT Inverter, 500Vdc, 48V Pure Sine wave, can parallel.

5.5kW 110A Pure Sine Wave Inverter - High voltage, can parallel connect.

MODEL NR 5548MH

IP Rating:

• IP21
• Not recommended for installation location with high humidity.
• If the inverter needs to be installed close to the ocean please make use of a dehumidifier.

Features:

• Programmable supply priority for PV, Battery or Grid.

• User adjustable charge current & voltage.
• Wide PV input range 60 - 500Vdc, 100A MPPT

• Can be parallel connected , also 3-phase.
• Output power factor 1.0

• PV & Grid complementary.
• Pure sine-wave Inverter.
• High voltage inverter.

Max Watt Output:

• Continuous: 5.5kW
• Surge: (5 seconds) : 11kW

Output and Charging Source Settings:

• Solar-Utility-Battery,  Solar-Battery-Utility & Utility-Solar-Battery.

• Solar only: 100A (maximum).
• Grid only: up to 60A.

Solar input specifications:

• 60 - 500Vdc solar input is the optimal working voltage range for these inverters.

• 6200W max solar input wattage.
• 18A max PV current input.

Monitoring & Setting :

• LCD screen.


Expansion: Single Inverter

• PV Panels maximum: 6200W
• 9 x 550W panels MAX
• PV Panels connection : series only.

• Peak Efficiency: 98%


Expansion: More Inverters

• Can be used as single inverter.

• Single-phase up to 7 units & 3-phase up to 6 units
• Please take note that the warranty will only be valid for up to 3 inverters connected in parallel. Contact us for approval on warranty for more than 3 inverters connected in parallel.

 Physical dimensions

• 565 x 390 x 200 mm
• 12KG

What's in the box

• Inverter
• User manual
• Parallel Cable
• Power Sharing Cable

IMPORTANT: THE CORRECT SETTINGS ON THE INVERTER WILL AID IN ENSURING OPTIMAL BATTERY LIFE.

Warranty:

12 Months Warranty

Please take note of the full warranty terms and conditions.
