Features:
Pure sine wave output.
Fed the power to city net.
High utilization of solar energy by using MPPT (maximum power point tracking) technology.
Over current protection.
Reverse polarity protection, avoid machine fault.
Support stackable (connect in parallel for higher output).
LED indicators reflect well working condition or machine fault.
Environment friendly.
Simple and safe to install.
Specifications:
Power
500W
Solar Panels
Vmp18-21V;Voc20-24V
DC MAX Input
600W
DC Input Range
10.5-28V
MPPT Voltage
15.5-20VDC
DC MAX Current
30A
AC MAX Output
550W
AC Output Range
230VAC(190-260VAC)
Frequency Range
50Hz/60Hz(Auto control)
Power Factor
>97.5%
THD
<5%
Phase Shift
<1%
Peak Efficiency
87%
Stable Efficiency
84%
Efficiency
230VAC(190-260VAC)
Peak Efficiency
87%
Stable Efficiency
85%
Protection
Islanding; short-circuit; converse connection; low voltage; over voltage; over temperature protection
Work Temperature
-25-65 degrees
Work Environment Humidity
0%~90%RH non-condensing
Grade of Waterproof
Indoor design
Show
1 red and 1 green
Cooling
Fan
Stand-by Power
2-3W
EMC
EN61000-6-3:2007 EN61000-6-1:2007
Grid Disturbance
EN 50178+EN 62109-1+VDE0126-1-12
Grid Detection
DIN VDE 1026 UL1741
Certificate
CE
Inverter Size
21 * 16.5 * 5.3cm / 8.26 * 6.46 * 2.08in
Inverter Weight
1.3kg / 2.86Lb
Package Size
31 * 21 * 11.5cm / 12.20 * 8.26 * 4.52in
Package Weight
1.75kg / 3.85Lb
Packing List:
1 * Micro inverter
1 * AC cord
1 * User manual
1 * User manual
