Specifications: Product Name: 6-Port PD 65W/100W Two-Way Fast Charge Mobile Power Module
Model Options: 3S 65W 4S 100W 5S 100W
Power Output: Up to 65W (3S) / 100W (4S & 5S)
Dimensions: 72mm x 27mm x 6mm
Supported Fast Charge Protocols: QC, PD, PPS, SCP, VOOC, AFC, FCP, SFC
Input Voltage: Type-C input supporting PPS and PD protocols (PD3.1, PD2.0, PPS)
Output Voltage Regulation: Low ripple output (C port Vpp < 6-9mV)
Protection Mechanisms: Short circuit, over-voltage, over-current, over-temperature protection
Features: 1. Universal Compatibility with Fast Charging Protocols
Supports a wide range of popular protocols, including QC, PD, PPS, SCP, and VOOC, ensuring seamless charging for diverse electronic devices.
2. Dual-Functionality: Two-Way Fast Charging
Allows both fast charging for connected devices and rapid self-charging, cutting downtime and enhancing convenience.
3. Multi-Level Protection for Safer Usage
Equipped with safeguards such as short circuit protection, over-voltage prevention, and temperature regulation to ensure secure operation.
4. Solar Panel Connectivity via MPPT Support
Facilitates compatibility with solar panel charging systems, providing an eco-friendly power source for long-term use.
5. Compact Design with Advanced Stability
Features solid capacitor filtration, low ripple output (<9mV), and efficient voltage control for reliable performance in minimal space.
Package Included: 1 x Mobile Power Module
1 x Wire Connector
