5V 4CH Bluetooth Relay Android Mobile App Remote Control Module Switch (Blue)..!
Product Information
FEATURES
Household automation: Bring Intelligence to your living
Only supports Android mobile phone with bluetooth function
Typical applications:
Home lighting system
Remote control switch
Remote locking
Smart Home / Home Automation
DC LED lighting
Fluorescent lamp
PLC
DC Motor
Fluorescent lamp
Automotive electronics
Industrial automation and control
SPECIFICATIONS
Material: PCB
Size: 73x76x17mm
Diameter of the location hole: 3mm
Power supply mode: DC5V
Standby current (all relay closed): 35mA
The first channel relay "open" 60mA; The second channel relay "open" 91mA; The third channel relay "open" 125mA;
The fourth channel relay "open" 155mA; Send via bluetooth APP command control relay conduction and disconnect
(You can also use your own APP to control relay, can be controlled by sending a simple instruction)
4 channel relay all with functions: inching, self-locking, interlocking, Normally "open" and normally “closed” relay
Communication mode: Bluetooth v2.1
Communication distance: 6-10m
Control mode: Bluetooth wireless, remote control, relay switch
Remote control: Four switch, normally open and normally closed functions
Control voltage: AC 85-265V 10A; DC 1-48V 10A
Bluetooth password: 1234
(The first time of use bluetooth for cell phone connection, needs to connect 2-3 times to be succeed, after that only needs once)
Operation instructions:
Explanation:
NO: Relay normally open contacts
COM: relay public contact
NC: relay normally closed contacts
"Open": NO connect COM, NC disconnect COM.
"Off": NO disconnect COM, NC connect COM.
“Inching”: Mobile terminal input "A0" (or B0 / C0 / D0), relay "open", "off" time delay 1 seconds
“Self-locking”: Mobile terminal input "A1" relay "open", input "A1" again, relay "off", and so on
“Interlocking”: Input "A2" mobile end, relay 1 "open", the other relay "off"; Enter "B2", relay 2 "open", the other relay "off", and so on
GENERAL
Classification
PRODUCT TYPE: Modules
Package
PACKAGE TYPE: Anti-static
PACKAGE CONTENTS: 1x Bluetooth Relay Android Mobile Remote Control Switch
Dimensions
DEPTH: 19 mm
HEIGHT: 77 mm
WIDTH: 54 mm
PRODUCT WEIGHT: 70 g
Package Contents
1x 5V 4CH Bluetooth Relay
