SELECTED OPTION:
VOLTAGE: 12V
Description: 1. Switching power supply, convertAC 110V-220VtoDC 12V 5A/DC 24V 2.5A.
2.Wide input voltage range, widely used in kinds of DCequipments,DC motor stepless speed adjustment,battery charging,Industrial automation, LED light strip display,student experiment,communications, etc.
3.Protections: Over-load, Over- voltage, Over-current, Short-circuit.
Specification: Product: Switching Power Supply
Type: AC/DC power
Model:YY-60
Transistor Connection: Full bridge
Input:AC 110-260V±15% 50HZ/60HZ
Output: 12V/24V±5%
Rated Power:60W
Modulation Mode: PFM
Cooling FanType: Intelligent temperature control
Working Temperature: -10a~+60a
Working Humidity: 20%~90%RH(nocondensation)
Size: 110*78*36mm
Package Included: 1 X Switching Power Supply
