Specifications:
DVR Parameters:
Video Compression: H.264
Video System: NTSC/PAL
Video Input/Output Interface: BNC
Video Input: 8 Channel
Video Output: 1 Channel
Other Video Output: VGA,HDMI
Audio Input / Output: RCA 1-Channel Input / RCA 1-Channel Output
Display Frame Rate: NTSC: 240 fps @D1 / PAL: 200 fps @D1
Display Resolution: NTSC: D1(704 x 480)/ PAL: D1(704 x 576)
Recording Frame Rate: NTSC: 240fps @CIF/ PAL: 240 fps @CIF
Record Mode: Time Schedule, Manual/Schedule, Motion Detection
Mobile Device OS Support: Blackberry, Windows Mobile, Symbian, iOS, Android
Network Function Mobile & Email Function, DVR Setting, Live Monitoring, IE Viewer
Network RJ45, 10M/100M
Net Protocol : DHCP and TCP/UDP
Remote Access: Remote Client Software and IE Browser
PTZ Control: RS-485
HDD Interface: SATA, Support between 250GB and 2TB
HDD Port: 1
Built-in HDD: No
Playback Mode: Frame by Frame, Fast Rewind, Fast Forward, Normal Play
Synchronous Playback (Channel): 8
USB: USB Backup/USB 2.0
Power Supply: 12V DC
Dimensions (LxWxH): 370 x 285 x 72
Bullet Camera Parameters:
Bullet Camera Image Sensor: 1/4 Color 800TVL CMOS
TV System: PAL/NTSC
Effective Pixels: NTSC: 512 (H) x 492 (V)/PAL: 512 (H) x 582 (V)
Lens (mm): 3.6
Features: Waterproof, Auto White Balance
Minimum Illumination: 0.0 Lux
S/N Ratio: 48dB
Video Output: 1.0Vp-p, 75ohms
Operating Temperature: -25F~122F / -32C ~50C
Power: 12V DC
Dimensions (LxWxH): 93 x 65 x 60
Material: Metal Shell
