8 CHANNEL HDMI DVR
Features: Advanced Functions
1.H.264 compression
2.Support Full HD 1080p output
3.Support IP camera
4.Quadplex operation
5.User management
6.Per channel configuration
7.NTP support for time synchronization
8.Motion detection marker
9.Up to 4 internal SATA HDDs
10.4/8/16CH audio recording
11.Mobile View software (I Phone support)
12.Remote™ for remote monitoring
13.Guard™ CMS for video management
14.Dual streaming
15.Support VBR/CBR recording mode Humane Technology
1.GUI 2.Touch panel 3.USB mouse 4.Control keyboard 5.IR remote control
Model: GD-3108Video: Input BNC × 8, 1.0 Vp-p, 75 ohm Main output: HDMI output 1024x768 , 720P, 1080I VGA output 1024x768, 1280x960, 1280x1024, 1920x1080(16:9) BNC output BNC x 1, 1.0 Vp-p, 75 ohm Call monitor output: BNC x 1, 1.0 Vp-p, 75 ohmAudio: Input D-SUB × 8, Line-In Outputï¼ÂMain Audioï¼ÂRCA × 1 Call Audio: RCA × 1Recording:Compression method: H.264 Pre alarm: Yes Recording Rate: NTSC 720 × 480 : Max 60 pps 720 × 240: Max 120 pps 360 × 240: Max 240 pps PAL 720 × 576: Max 50 pps 720 × 288: Max 100 pps 360 × 288: Max 200 ppsStorage:Built-in Storage Interface : × 2 SATA for HDD and DVD+RW Cartridge / DVD+RW: Optional Export: × 2 USB 2.0 Port, Supports ThumbDrive, or DVD+RWAlarm:Alarm input: × 8, D-SUB (TTL) Alarm output: × 1, D-SUB, 1A / 30VDC or 1 A / 120VAC Alarm Detection: Yes Video loss Detection: Yes Motion Detection: 16 × 12 Grid Array, sensitivity, Trigger level adjustableCommunication:Network connectivity: RJ45, 10/100/1000 Mbps Ethernet, Supports PPPoE/ DDNS/ DHCP/SMTP/NTP Remote control software: IE 7,Firefox,3G/3.5G Phone,Java AP,CMS 64 Remote operation: Monitoring,Playback,Recording,System setup,Dome camera control,ArchivingGeneral:Operation temperature: 0 °C ~ 40 °C (32 °F ~ 104 °F) Power consumption: AC 100 ~ 240V, 50-60Hz, 60W adaptor
