8 Channel (video & Audio) Digital Security Camera Recorder DVR Card (4008A)

1、

Hardware requirements:

Motherboard:

INTEL 845/865/945 845G/865G/945G

INTEL 946/965

The suggestion chooses to use 845G/865G/945G integrated graphics controller Mainboard;

INTEL 946G/965G integrated VGA Nonsupport;

VGA:

1、ATI:

ATi Rage 128/Rage 128 Pro

ATi Radeon 7500/9000/9200/9600

ATi Radeon 9250/9550

ATi Radeon X300/X550/X600 (PCI-E)

2、nVIDIA

GeForce2 MX400
GeForce4 MX440

System configuration requirements :

1、4 channels：

(1) CPU: Intel Celeron 1.7G or above;
or Pentium 4 1.4G or above;
(2) Mainboard： Intel 845 865 945;
* Integrated VGA is recommended.
(3) Memory： 128M DDR or above;

2、8 channels：

(1) CPU: Intel Celeron D 2.4G or above;
or Pentium 4 2.0G or above;
(2) Mainboard： Intel 845 865 945 ;
* Integrated VGA is recommended.
(3) Memory： 256M DDR or above;

3、12 channels：

(1) CPU: Intel Celeron D 2.8G or above;
or Pentium 4 2.4G or above;
(2) Mainboard： Intel 865 945 (Dual-Channel);
* Integrated VGA is recommended;
(3) Memory： 2 pcs 256M DDR400 or 2 pcs 512M DDR2;
(Dual-Channel)

4、16 channels：

(1) CPU: Intel Celeron D 2.93G or above;
or Pentium 4 2.66G or above;
(2) Mainboard： Intel 865 945 (Dual-Channel);
* Integrated VGA is recommended;
(3) Memory： 2 pcs 256M DDR400 or 2 pcs 512M DDR2;
(Dual-Channel)

5、20 channels：

(1) CPU: Intel Pentium 4 3.00G or above;
or Pentium D 2.66G or above;
(2) Mainboard： Intel 865 945 (Dual-Channel);
* Integrated VGA is recommended;
(3) Memory： 2 pcs 256M DDR400 or 2 pcs 512M DDR2;
(Dual-Channel)

6、24 channel：

(1) CPU: Intel Pentium 4 3.20G or above;
or Pentium D 2.66G or above;
(2) Mainboard： Intel 865 945 etc (Dual-Channel);
* Integrated VGA is recommended;
(3) Memory： 2 pcs 256M DDR400 or 2 pcs 512M DDR2;
(Dual-Channel)

6、32 channels：

(1) CPU: Intel Pentium D 2.8G or above ;

(2) Mainboard： Intel 945 965 (PCI-E,Dual-Channel);
* 945 integrated VGA is recommended;
* 965 integrated VGA Nonsupport;
(3) Memory： 2 pcs 512M DDR2(Dual-Channel);
