Thermal Magnetic Circuit Breaker, C Curve, S200M, 4 A, 1 Pole, 230 VAC, DIN RailProduct InformationProduct Range: S200MNo. of Poles: 1 PoleVoltage Rating VAC: 230VACCircuit Breaker Mounting: DIN RailProduct OverviewThe S200/S200 M System pro M compact series from ABB are miniature circuitbreakers. These are current limiting overcurrent protective devices. They havetwo different tripping mechanisms, the delayed thermal tripping mechanism foroverload protection and the magnetic tripping mechanism for short circuitprotection. S200 System pro M compact series are available in differentcharacteristics (B, C, D, K, Z), configurations (1P, 1P+N, 2P, 3P, 3P+N, 4P),breaking capacities (up to 25 kA) and rated currents (up to 63A).Complies with IEC/EN 60898-1, IEC/EN 60947-2, UL 1077, UL 489, CSA 22.2 No. 235,CSA 22.2 No. 5Clear contact position indication in red/greenBusbar slot in the back for better visibility during installationHigh performance at an increased rated voltageApplicationsIndustrial, Safety
