abit IX 38 GT Qaud FSB 1600 Supported 45nm Ready Intel X38 Express Chipset

# LGA 775# 45 nm CPU ready# Intel® X38 Express# FSB 1600# Dual DDR2 1066/800# PCI-E X16# SATA 3G RAID# PCI-E GbE# IEEE1394# 7.1 CH HD Audio# SilentOTES™# µGuru™ Tech# RoHS Compliancy# CPU Supports Intel® Core™ 2 Duo / Quad processors with 1600/1333/1066/800MHz FSB# Supports Intel® Core™ 2 Extreme/Quad/Duo & Pentium® Extreme Edition, Pentium® D, Pentium® 4 Processors, Pentium® Dual Core# Digital PWM Designation provide high quality and efficient power# Chipset Intel® X38 Express / ICH9R Chipset# Memory 4 X 240-pin DIMM sockets support max. memory capacity 8GB# Supports Dual channel DDR2 1066/800/667 Un-buffered Non-ECC memory# LAN On board PCI Gigabit LAN controller supports 10/100/1000M Ethernet# Audio On board 7.1 CH HD Audio CODEC# Supports auto jack sensing and optical S/PDIF In/Out# HDMI audio ready header (S/P DIF header)# Expansion Slots 2 x PCI-E X16 (support PCI Express 2.0), 1 x PCI-E X16 (x4 bandwidth), 1 x PCI-E X1, 2 x PCI# Internal I/O 1 x Floppy Port supports up to 2.88 MB# 1 x ATA 133/100/66 IDE connector# 6 x SATA 3Gb/s connectors# 1 x IEEE1394, 4 x USB header (support 8 ports)# 1 x FP-Audio# Back Panel I/O 1 x PS/2 Keyboard, 1 x PS/2 Mouse# abit Silent OTES™# 1 x S/P DIF In, 1 x S/P DIF Out# 2 x eSATA# 7.1 CH Audio connector (Front, Line-in, MIC-in, Center/Subwoofer, Surround, Rear Surround)# 1 x 1394, 4 x USB 2.0, 1 x RJ-45 LAN connector,# Clear CMOS Button# Serial ATA 6 x SATA 3Gb/s offer by Intel® ICH9R support Intel® Matrix Storage Tech(AHCI & RAID0/1/5/10)# 2 x eSATA 3Gb/s through JMicron® JMB363 support 0,1JBOD RAID# IEEE 1394 Supports 2 Ports IEEE 1394 at 400Mb/s transfer rate.# Form Factor ATX form factor 305 x 245mm# PCB Color: Blue# RoHS 100% lead-free process and RoHS compliant# abit Engineered abit µGuru™ Technology# abit Silent OTES™ Technology# 100% Low ESR and high ripple conductive polymer aluminum solid state capacitors# New Generation digital PWM# EZ for CCMOS# On board LED Lighting# Quick Power On/Off & Reset buttons# right angle SATA connectorsabit Engineeredabit Engineered abit µGuruWith abit's unique µGuru technology now even the most novice users can fully monitor and control their system including voltages, fans and temperatures; it's all just a click away. The more advanced you become, the more you will appreciate the multitude of fine tuning features abit's µGuru technology holds for you.abit Engineered OC Guru - AutoDrive™By enabling AutoDrive, you can automatically apply different overclocking settings for different applications.abit Engineered Hardware MonitoringMonitor temperatures, voltages and fan settings in real time and with zero CPU usage.abit Engineered Dedicated fan controlKeep control over your hardware. abit Fan EQ™ helps you keep an eye on your motherboard fans.abit Engineered One Click BIOS UpdateWith abit's BIOS flash utility you can easily update your motherboard BIOS online or offline.abit Engineered Auto-Detect Hardware InfoThe abit BlackBox auto-detects hardware info for quick communication between users and abit Tech support.abit Engineered abit SoftMenu™The original jumperless motherboard design allows for CPU setting changes completely through the BIOS. For GigaOverclocking! Boost your PC's Performance by up to 50%. Convenient and easy-to-use fine tuning from within a self-explanatory BIOS menu.abit Engineered abit CPU ThermalGuard™The abit CPU ThermalGuard™ technology prevents the CPU from overheating and burning up in the case of any hardware cooling malfunction. This hardware thermal protection automatically shuts down your system when the CPU temperature reaches a certain threshold.Need More Info Search for it on Google
