Product details
AC Input Detail:
1) AC Input Voltage Range: 100-240V
2) AC Input Current: 1500mA
3) Input Frequency Range: 47-63Hz
4) No Load Power Consumption: <0.5W
5) Inrush Current: 30A
6) Hold Up Time: 5ms Min.at100Vac input and output Max .Load.
7) Rise Time: 30 ms Max
8) Line Regulation: ±2%
9) Leakage Current: < 0.25mA
DC Output Detail:
1) DC Voltage Range: 3-24V
2) DC Current Range: 100-4000mA
3) Total Regulation:
4) Ripple & Noise: 100 m Vp-p
5) Working Efficiency: 80%
6) Protections: Short Circuit Protection, Over Voltage Protection, Over Current Protection, Open Circuit Protection
Environmental Requirement:
1) Operating Temperature: 0¿ -- +40¿
2) Storage Temperature: -10¿ -- +55¿
3) Operating Humidity: 5%(0¿)~90%(40¿) 72h Full Load
4) Storage Humidity: 3%-98%
Mechanical Features:
1) AC Plug: UK/US/EU Standard
2) DC Jack(Plug): 5.5*2.1mm, 5.5*2.5mm, 3.5*1.35mm,etc
3) DC Cable Length: 1.5m
4) Case Dimension: L119*W61*H37mm
5) Weight: 0.30KG
6) Colour: Black
Note:
1¿ AC Rated Voltage Input: 100-240V
2¿ AC Max Voltage Input: 90-264V
3¿ AC Input Current: 1500mA
4¿ DC Voltage output Range: 3-24V
5¿ DC Current output Range: 100-4000mA
6¿ Approval & Safety: UL,CE,PSE,EK,SAA,C-tick, S-mark, BS,GS,CB,FCC,CEC
What you will get:
1 x AC Power Adaptor
I ONLY POST TO ADDRESSES IN SOUTH AFRICA - NO INTERNATIONAL SALES
